Swing Gate

The AGZ-Z2148L column-type intelligent swing gate is made of stainless steel, and is characterized with a beautiful appearance, firm structure, easy deployment, and durability. It can be selectively matched with various door access control devices, such as door access control managers, face recognition apparatuses, and fingerprint recognition apparatuses, to achieve the door access control function, and can also achieve some additional functions such as attendance and charging. It is applied to places where pedestrian flow control is required, such as gates, subways, stations, docks, clubs, and hotels, etc., to effectively manage and control pedestrian flow.

Key Features

  • Solid Body

Made of 304 stainless steel, corrosion resistant, wear resistant, high tempera ture resistant, oxidation resistant, and durable

  • DC Motor Driving

Brushless DC motor, digital drive, smooth speed regulation, automatic deceleration in place, and stopping slowly

  • Diversified Access Rights

Selectively matched with a variety of door access control devices, expandable to access control authentication functions such as face recognition,card swiping, and QR code swiping

  • Automatic Protection

When blocked by an external force, the arm will fall automatically and alarm to prevent device from damaging and personal injury

  • Remote Control And Management

Unified external interface connected with other read-write device, to achieve remote control and management.

  • Unidirectional Or Opposing Traffic

The Gate can be swing by ±90°, and support one-way or two-way access.


Production Specifications

Product modelAGZ-Z9000CAGZ-Z9010CAGZ-Z9200C
Body And Side Frame Material304 Stainless Steel 304 Stainless Steel 304 Stainless Steel
Gate MaterialStainless steel or acrylicStainless steel or acrylicStainless steel or acrylic
Lane Width800mm, Lane width <= 800mm single unit800mm, Lane width <= 800mm single unit800mm, Lane width <= 800mm single unit
ColorStainless steel original colorStainless steel original colorStainless steel original color
Dimensions (L*W*H)1500*118 *980mm1600*116 *950mm1600*200*950mm
Power SupplyAC220V±10% 50HzAC220V±10% 50HzAC220V±10% 50Hz
Device PowerTotal power: 50W Body: cylindricalTotal power: 50W Body: cylindricalTotal power: 50W Body: cylindrical
Appearance ShapeGate:Bent or rectangular flatGate:Bent or rectangular flatGate:Bent or rectangular flat
Passing Speed25 persons/minutes25 persons/minutes25 persons/minutes
Swinging Angel90°(one-way access) and ±90°(two-way access) optional90°(one-way access) and ±90°(two-way access) optional90°(one-way access) and ±90°(two-way access) optional
Input InterfaceSwitching value, 12v level signal (pulse width 100ms)Switching value, 12v level signal (pulse width 100ms)Switching value, 12v level signal (pulse width 100ms)
Communication ProtocolRS485 or TCP/IPRS485 or TCP/IPRS485 or TCP/IP
Working Tempature-30° to +70°C-30° to +70°C-30° to +70°C
Working Humidity<95%, no condensation <95%, no condensation <95%, no condensation
MCBF>10million cycles>10million cycles>10million cycles

SWING GATE AGZ-Z9200C

The AGZ-Z9200C is a concise intelligent swing gate. The gate is integrally made of 304 stainless steel.

SWING GATE AGZ-Z9010C

The AGZ-Z9010C serial intelligent swing gate is made of 304 stainless steel and integrally shaped by cold-rolled plate spraying.

SWING GATE AGZ-Z9000C

The AGZ-Z9000C intelligent swing gate uses the brushless DC motor and servo control technology, which is characterized with good synchronism, stable operation, and a low failure rate. The product can be integrated with various access control system, like face recognition device, IC cards, QR code
